Sirio - IN-GLASS LTE & WLAN / SMA-m

Sirio - IN-GLASS LTE & WLAN / SMA-m

Product code: 221680293
Factory code: 2216802.93

Upgraded - Very low profile multi band antenna. Multi bands antenna for LTE, GSM dual-band, UMTS, WiMAX, Wifi.

Mount with 3M adhesive tape for permanent installation on glass, plastic, wall and other surfaces (except metallic parts).

Frequency range: 800 - 960 / 1.71 - 5.925 GHz
Out of stock - Longer delivery time
€20.62 (20.62 excl. 0% VAT)

Electrical data

  • Electrical type: On-glass indoor
  • Gain: 0 dBd, 2.1 dBi all bands
  • VSWR: See the product manual under downloads
  • Power continues: 800 - 2700 MHz: 10 Watts (CW) / 2.7 - 3.8 GHz: 6 Watts (CW) / 3.8 - 5.925 GHz: 5 Watts (CW)
  • Impedance: 50 Ohm
  • Polarization: Linear vertical / Linear horizontal /
  • Cable: Yes
  • Cable length: 3 meter / RG 174

Mechanical data

  • Materials: Copper, thermoplastic UV stabilized, PCB
  • Length: 77 mm
  • Height: 10 mm
  • Width: 57 mm
  • Weight: 70 gram
  • Mounting type: On glass and other surfaces

Inside the box

  • Antenna: Yes
  • Radio connector: SMA-male
  • Mounting parts: Yes
  • Antenna cable: Yes
  • Installation manual: English
