Sirio - Performer 5000 LED 3/8

Product code: 2005000

Factory code: 2418505.03/LED

Barcode: 8056182115041

200 mm stainless steel shaft. Unique LED PCB that light up when transmitting. High power vehicular antenna working on 27 MHz or 10 meter band. Low loss coil, 2.5 mm copper wire.

Frequency range: 27 - 30 MHz

Shipped today - Stock: 6

€62.94 (52.02 excl. 21% VAT)

Electrical data

• Electrical type: Centre loaded
• VSWR: ≤ 1.2
• Bandwidth: 2600 kHz (230 channels) ≤ 2.0
• Maximum continuous power: 1500 Watts (CW)
• Power peak: 5000 Watts (CW) / duty cycle, 5 seconds on, 5 seconds off
• Impedance: 50 Ohm
• Polarization: Linear vertical

Mechanical data

• Materials: Copper, chromed brass, stainless steel 17/7 PH, thermoplastic UV
• Height: 2080 mm
• Weight: 480 gram
• Mounting type: On 3/8 female (stud) mount

Inside the box

• Antenna: Yes
• Installation manual: English, Italian

Downloads

• Datasheet: Id 441 03 02 2016 p 5000 3 8 led
