Sirio - SPO 350-5

Product code: 2115120350

Factory code: 2115120/350

Barcode: 8056182113856

New series of wide band omni-directional base station antennas for UHF band, 350 - 400 MHz. The fiberglass protection random and the anodized aluminium parts guarantee robustness and long life to all the SPO-antennas series. They are supplied with two strong extruded aluminium brackets and stainless steel hardware for a good installation on the mast.

Frequency range: 350 - 400 MHz

Out of stock - Longer delivery time

€149.96 (123.93 excl. 21% VAT)

Electrical data

• Electrical type: Colinear
• Gain: 3 dBd, 5.15 dBi
• VSWR: ≤ 1.5
• Maximum continuous power: 75 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical

Mechanical data

• Materials: Anodized aluminium, brass, stainless steel, fiberglass, EPDM rubber
• Mast Ø: 35 - 54 mm
• Max wind resistance: 180 km/h
• Height: 1380 mm
• Weight: 1240 gram
• Mounting type: On mast
• Antenna connector: N-female

Inside the box

• Antenna: Yes
• Mounting parts: Yes
• Installation manual: English

Downloads

• Datasheet: Id 385 04 09 2020
