Stabo - XM 3004E-R VOX

Product code: 30131
Factory code: 30131
Barcode: 4010384301316

The Stabo XM 3004E-R VOX is a mobile CB radio device and can be used on 12 and 24 Volt. The XM 3004E has an adjustable VOX function (5 levels) that makes it possible to communicate handsfree with the optional Stabo VOX microphone. This versions is included an original din mount from Stabo.

Frequency range: 26.965 - 27.405 MHz
Out of stock - Longer delivery time
€285.08 (285.08 excl. 0% VAT)

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: 4 Watt
  • Channels: 40 AM / FM
  • Display type: LCD display
  • Display colors: Green / Orange / Purple / Blue / Cyaan / Yellow / Clear Blue
  • VOX Function: Yes
  • Noise blanker: Yes
  • Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
  • Emergency channel: Yes
  • Scan function: Yes
  • Quick channel selection: Yes
  • External speaker socket: Yes
  • TOT (time out timer): Yes
  • Din mount: Yes
  • External VOX socket: Yes
  • Roger Beep: Yes

Electrical data

  • Voltage: 13,8 Volt / 24 Volt /
  • Operating temperature: -10° to +55° C

Transmitter

  • Audio frequency response: 300 Hz - 3 kHz
  • Microphone sensitivity: <3 mV
  • Frequency allowance: ± 600 Hz
  • Drain: 13.2 Volt: 2 A max / 24 Volt: 2 A max

Receiver

  • AM sensitivity: ≤ -107 dBm 20 dB SINAD
  • FM sensitivity: ≤ -107 dBm 20 dB SINAD
  • Frequency response: 300 Hz - 3 kHz
  • Adjacent channel selectivity: 60 dB
  • Maximum audio power: 2 Watt
  • Internal speaker: 8 Ohm
  • Squelch sensitivity: min. 0.2 μV
  • Image rejection: 70 dB
  • Drain: 300 mA nominal / 750 mA max.

Mechanical data

  • Length: 165 mm
  • Height: 35 mm
  • Width: 115 mm (without DIN-mount)
  • Weight: 600 gram (without DIN-mount)
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 6 pin connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Power lead: 1 pcs
  • DIN mount: 1 pcs
  • User manual: English, German, French, Polish,
