Stabo - XM 3006E-R VOX

Stabo - XM 3006E-R VOX

Product code: 30120
Factory code: 30120
Barcode: 4010384301200

The Stabo XM 3006E-R VOX including Stabo DIN mount is a CB transceiver with 40 channel and the Stabo XM 3006E-R VOX has a controllable VOX function directly from the front of the radio. And the Stabo XM 3006E has a USB connection (5V 2.1A) on the front of the device. The Stabo XM 3006E can be used on both 12 and 24 Volt.

Frequency range: 26.965 - 27.405 MHz
Shipped today - Stock: 8
€345.95 (285.91 excl. 21% VAT)

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: 4 Watt
  • Channels: 40 AM / FM
  • Front speaker: Yes
  • Display type: LCD display
  • Display colors: Green / Orange / Purple / Blue / Cyaan / Yellow / Clear Blue
  • VOX Function: Yes
  • USB: Yes
  • Noise blanker: Yes
  • Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
  • Emergency channel: Yes
  • Scan function: Yes
  • External speaker socket: Yes
  • S-meter: Yes
  • MIC gain: Yes
  • TOT (time out timer): Yes
  • Din mount: Yes
  • VOX gain: Yes
  • External VOX socket: Yes
  • Roger Beep: Yes

Electrical data

  • Voltage: 13,8 Volt / 24 Volt /
  • Operating temperature: -10° to +55° C

Transmitter

  • Audio frequency response: 300 Hz - 3 kHz
  • Microphone sensitivity: <3 mV
  • Frequency allowance: ± 600 Hz
  • Drain: 13.2 Volt: 2 A max / 24 Volt: 2 A max

Receiver

  • AM sensitivity: ≤ -107 dBm 20 dB SINAD
  • FM sensitivity: ≤ -107 dBm 20 dB SINAD
  • Frequency response: 300 Hz - 3 kHz
  • Adjacent channel selectivity: 60 dB
  • Maximum audio power: 2 Watt
  • Internal speaker: 8 Ohm
  • Squelch sensitivity: min. 0.2 μV
  • Image rejection: 70 dB
  • Drain: 300 mA nominal / 750 mA max.

Mechanical data

  • Length: 165 mm
  • Height: 35 mm (without DIN-mount)
  • Width: 115 mm (without DIN-mount)
  • Weight: 600 gram (without DIN-mount)
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 6 pin connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Power lead: 1 pcs
  • DIN mount: 1 pcs
  • User manual: English, German, French, Polish,
