Super Star - 3900

Product code: 3900
Barcode: 8435550803481

Available in the week of 23 January 2023, pre-orders are possible.

The Super Star 3900 is a 27 MHz CB mobile radio with 40 multi-standard channels and AM/FM/USB/LSB with a power of 4W (AM/FM) and 12W in sideband (SSB). The new Super Star 3900 maintains the essence of the classic model recognizable by its iconic design, its control buttons, the microphone input on the side, the analog meter, among others.

In 2023, the new Super Star 3900 comes with some improvements, such as: display with function indicator and screen lighting adjustment, new handheld microphone with channel change buttons (Up/Down), new board design with micro components which translates into a reduction in the overall weight: improvements that in no way alter its essence and that make the Super Star 3900 remain stronger than ever as an icon of the citizen band radio.

Frequency range: 26.965 - 27.405 MHz
Out of stock - Longer delivery time
€165.25 (165.25 excl. 0% VAT)

Features

  • Modulation: AM / FM / LSB / USB
  • Multi-bands: Yes
  • Output power: AM/FM: 4 Watt / SSB: 12 Watt
  • Channels: 40 AM / FM
  • Display type: Multi-color backlight
  • Display colors: Red
  • Export version: AM/FM: 12 Watt / SSB: 40 Watt / 25.615 - 30.105 MHz
  • VOX Function: Yes
  • Noise blanker: Yes
  • Squelch: Automatic squelch / Manual squelch /
  • Scan function: Yes
  • Memory channels: Yes
  • External speaker socket: Yes
  • External S-meter socket: Yes
  • External PA socket: Yes
  • S-meter: Yes
  • MIC gain: Yes
  • RF gain: Yes
  • TOT (time out timer): Yes
  • Dual watch: Yes
  • RX Noise reduction: Yes
  • TX Noise reduction: Yes

Electrical data

  • Voltage: 13,8 Volt
  • Frequency stability: ± 5 ppm
  • Fuse: 10A (250 Volt)
  • Operating temperature: -20° to +55° C
  • Frequency control: PLL synthesizer
  • Operating mode: F3E (FM) / A3E (AM) / J3E (SSB)

Transmitter

  • Audio frequency response: 450 Hz - 2.5 kHz
  • Current: 5 A
  • Distortion: <10%

Receiver

  • Frequency response: 300 Hz - 2.8 kHz
  • Maximum audio power: 3 Watt
  • Internal speaker: 8 Ohm, round
  • SSB sensitivity: 0.25 µV for 10 dB (S+N)/N at greater than 1/2 Watt of audio output.
  • AM sensitivity: 1.0 µV for 10 dB (S+N)/N at greater than 1/2 Watt of audio output.
  • FM sensitivity: 1.0 µV for 20 dB (S+N)/N at greater than 1/2 Watt of audio output.
  • IF frequencies: AM/FM: 1st 10.695 MHz / 2nd 455 kHz / SSB: 1st 10.695 MHz
  • Image rejection: More than 65 dB
  • Automatic Gain Control (AGC): Less than 10 dB change in audio output for inputs from 10 to 100,000 mV
  • AM/FM selectivity: 6 dB at 3 kHz / 50 dB at 9 KHz
  • SSB selectivity: 6 dB at 2.1 kHz / 60 dB at 3.3 KHz
  • Adjacent channel selectivity AM/FM: 60 dB
  • Adjacent channel selectivity SSB: 70 dB

Mechanical data

  • Length: 287 mm
  • Height: 61 mm
  • Width: 200 mm
  • Weight: 1500 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 4 pin connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • Power lead: 1 pcs
  • User Manual: English
