Wouxun - KG-D828

Product code: 34828

Barcode: 6946351706106

DMR dual band VHF / UHF (digital and analogue)

Frequency range: TX/RX: 136-174 / 400-470 Mhz

Out of stock - Longer delivery time

€149.96 (123.93 excl. 21% VAT)

Specifications:

• Channel: 3072

• Contacts: 1024
• Receiving Group: 255
• Areas: 250
• Scan List: 16
• Band: UHF and VHF
• Program Key: Yes
• Digit Voice Encryption: Yes
• Emergency Alarm: Yes
• VOX Function: Yes
• Priority Channel: Yes
• Scan TX Designated Channel: Yes
• Low Battery Power Off: Yes
• One Touch Relay / Talkaround: Yes
• Transmit Time-out Alert: Yes
• FM Radio: Yes
• Radio Program Password: Yes
• Power Save Mode: Yes
• Tail Elimination: Yes
• Lone Worker: Yes
• Radio Disable or Enable: Yes
• ARTS: Yes
• Detection: Yes
• Call Alert: Yes
• Flashlight: Yes
• CTCSS Encoding And Decoding , Support Non-standard: Yes
• DTMF Encoding and Decoding: Yes
• Firmware Upgrade: Yes

Integration:

• Frequency Range: 136-174 / 400-480 MHz / 65-108MHz FM(RX)
• Channel Number: 3072
• Operating Temperature: -20??+40?
• Antenna Resistance: 50Ohm
• Working Voltage: 7.4 VDC
• Weight: 300 g
• Size: 64 x 41 x 130 (mm)

Transmitter:

• FM Modulation: 12.5KHz : 11KOF3E , 25KHz : 16KOF3E 4FSK Digit Modulation: 12.5KHz(Data Only) : 7K60FXD / 12.5KHz(Data+Voice) : 7K60FXE

• Adjancent Channel Power: ?-60dB
• Frequency Stability: ±1 PPM
• Audio Distortion: ?5%
• Vocoder Type: AMBE+2TM
• Audio Response: +1dB~-3dB
• Digital Protocol: ETSI-TS102 , 361-1 , 361-2 , 361-3
• Bit Error Ratio: ?5%
• Modulation Limit: ±2.5KHz@12.5KHz
• Output Power: , VHF: 5/1 Watts / UHF: 4/1 Watts

Receiver:

• Analog Receive Sensitivity: 0.25µV@12dB SINAD
• Digital Receive Sensitivity: 0.25µV(BER:5%)
• Adjacent Channel Selectivity: ?60dB@12.5KHz
• Audio Response: +1dB~-3dB
• Audio Distortion: ?5%
• Audio Power: 1W
• Inter Modulation: ?65dB
