Zetagi - B153

Product code: 10000153

The Zetagi B153 is family off the MosPower series and uses mosfets that allow to obtain excellent results. Low signal distortion, high reliability and beter performance. The max. output power off the amplifier is 100 Watts AM-FM and 200 Watts SSB (PEP).

Frequency range: 26-30 MHz
Out of stock - Longer delivery time
€58.64 (58.64 excl. 0% VAT)

Electrical data

  • Input power (Watts): 0.5-5 AM-FM / 2-8 SSB
  • Max output power (Watts): 100 AM-FM
  • Max output power SSB (Watts): 200 (PEP)
  • Impedance: 50 Ohm
  • Inversion polarity protection: Yes
  • Electronic switch: Yes
  • Cooling fans: No
  • Input energy/power: 8-10 A

Mechanical data

  • Input connector: UHF (PL) female
  • Output connector: UHF (PL) female
  • Length: 120 mm
  • Height: 45 mm
  • Width: 130 mm
  • Weight: 700 gram
  • Color: Silver

Inside the box

  • Amplifier: Yes
  • DC power cord: Yes
  • Installation manual: English
