Zetagi - LA0546V

Product code: 546

The Zetagi LA0546V is a HF power amplifier suitable for the 155 - 165 MHz frequency. The input power is 1 - 3 Watts and the max. output power of the amplifier is 45 Watts AM-FM-SSB

Frequency range: 155 - 165 MHz
Shipped next business day
€99.13 (99.13 excl. 0% VAT)

Electrical data

  • Input power (Watts): 1 - 3 AM-FM-SSB
  • Max output power (Watts): 45 AM-FM
  • Max output power SSB (Watts): 45 SSB
  • Intermittent operation: 1'on 1' off (@R.temp = 21°C)
  • Impedance: 50 Ohm
  • Fuse: 1x 5 A

Mechanical data

  • Input connector: UHF (PL) female
  • Output connector: UHF (PL) female
  • Length: 120 mm
  • Height: 44 mm
  • Width: 130 mm
  • Weight: 700 gram

Inside the box

  • Amplifier: Yes
  • Installation manual: English, German, French, Italian,
