Zetagi - LA1080V

Product code: 1080

The Zetagi LA1080V is a HF power amplifier suitable for the 140 - 170 MHz frequency. The input power is 2 - 18 Watts and the max. output power of the amplifier is 100 Watts AM-FM-SSB.

Frequency range: 140 - 170 MHz
Out of stock - Longer delivery time
€188.39 (188.39 excl. 0% VAT)

Electrical data

  • Input power (Watts): 2 - 18 AM-FM-SSB
  • Max output power (Watts): 100 AM-FM
  • Max output power SSB (Watts): 100 SSB
  • Intermittent operation: 1'on 1' off (@R.temp = 21°C)
  • Impedance: 50 Ohm
  • Fuse: 2x 5 A

Mechanical data

  • Input connector: UHF (PL) female
  • Output connector: UHF (PL) female
  • Length: 160 mm
  • Height: 44 mm
  • Width: 120 mm
  • Weight: 1450 gram

Inside the box

  • Amplifier: Yes
  • Installation manual: English, German, French, Italian,
