Zetagi - P27M

Product code: 921506

The Zetagi P27M is an antenne pre-amplifier escpecially suitable for CB radios. The pre-amplifier can be used on AM-FM-SSB and has 2 UHF (PL) connectors.

Frequency range: 26-30 MHz
Out of stock - Longer delivery time
€36.32 (36.32 excl. 0% VAT)

Electrical data

  • Max output power (Watts): 15 AM-FM
  • Max output power SSB (Watts): 50 (PEP)
  • Pre-amplifier: Yes
  • Transmission Insertion Loss: 0.2 dB
  • Current drain: 100 mA
  • Gain: 25 dB (adjustable)

Mechanical data

  • Input connector: UHF (PL) female
  • Output connector: UHF (PL) female
  • Length: 45 mm
  • Height: 45 mm
  • Width: 110 mm
  • Weight: 220 gram

Inside the box

  • Amplifier: Yes
  • DC power cord: Yes
  • Installation manual: English
