Zetagi - SW2

Product code: 900030

The Zetagi SW2 is a automatic 2 way antenna switch with a UHF (PL) female input connector and 2x UHF (PL) female output connectors.

Frequency range: 15-50 MHz

Note - Discontinued

€ -- (Discontinued)

Electrical data

• Maximum continuous power: 1 W
• Power peak: 25 W
• Impedance: 50 Ohm

Mechanical data

• Connector(s) type in: UHF (PL) female
• Connector(s) type out: UHF (PL) female
• Length: 110 mm
• Height: 65 mm
• Width: 40 mm
• Weight: 200 gram
