Zetagi - TM 535

Product code: 900021

The Zetagi TM 535 is a SWR and Power meter with a built-in matcher function for HF frequencies between 1.5 - 30 MHz. The cross needle meter gives you direct reading of Forward Power, Reflected Power and SWR without any setting. AVG / PEP switch to select average power or SSB / PEP.

You can connect two antennas and a dummy load to one of the SO-239 connectors on the backside. To the binding posts you can connect a balanced line or a wire antenna and ground. With the 'antenna' switch on the front you can select the antenna that you want to use.

Frequency range: 1.5 - 30 MHz
Shipped next business day
€342.11 (342.11 excl. 0% VAT)

Electrical data

  • Power range: 50 / 500 Watts
  • Testing function: SWR and Power (FWD and REF / AVG and PEP)
  • Input impedance: 10 - 500 Ohm (unbalanced) / 100 - 3000 Ohm (balanced)
  • Output impedance: 50 Ohm

Mechanical data

  • Input connector: UHF (PL) female
  • Output connector: 3x UHF (PL) female, 4x binding posts
  • Length: 210 mm
  • Height: 90 mm
  • Width: 270 mm
  • Weight: 2700 gram

Inside the box

  • Meter: Yes
  • Matcher: Yes
  • Installation manual: English, French, German, Italian
