Zetagi - V-4

Product code: 905007

The Zetagi V-4 is a 4 way antenna switch with a UHF (PL) female input connector and 4x UHF (PL) female output connectors.

Frequency range: Up to 30 MHz
Out of stock - Longer delivery time
€34.67 (34.67 excl. 0% VAT)

Electrical data

  • Impedance: 50 Ohm
  • Insertion loss: Less than 0.2 dB
  • Max output power: 500 W AM

Mechanical data

  • Connector(s) type in: UHF (PL) female
  • Connector(s) type out: UHF (PL) female
  • Length: 105 mm
  • Height: 38 mm
  • Width: 110 mm
  • Weight: 350 gram
