JCD - 201M P8 HF Proof

Product code: 401203

The JCD 201M 8P HF Proof is a very solid desk microphone and will be delivered with a free adapter cable for Kenwood radios with a RJ45 connector. The JCD 201M has many functions to set and it is possible to connect 2 radios on the microphone.

Separately are RJ45 adapter cables available for Icom, Yaesu and Alinco radios available.

Always check carefully if your transceiver is compatible with your version of the JCD-201M microphone. We are not responsible for any damage caused due wrong usage (or wiring) of the microphone to your microphone or transceiver.

Shipped next business day
€119.95 (99.13 excl. 21% VAT)

Features

  • Up down: Yes
  • Echo Function: Yes
  • TX warning: Yes
  • Connector for optional PTT: Yes
  • Microphone type: Power microphone

Electrical data

  • HF proof: 0-100 Watts

Mechanical data

  • Microphone connector: RJ45

Microphone wiring

  • Up: Pin 1
  • DC: Pin 2
  • Ground: Pin 3
  • PTT: Pin 4
  • Mic ground: Pin 5
  • Mic audio: Pin 6
  • Not connected: Pin 7
  • Down: Pin 8
